Description:

Mahindra eMax sub-compact tractors are surprisingly versatile, offering powerful performance on our smallest platform.

Specifications:

• Engine:
• Type: 4-stroke, Naturally Aspirated, Indirect Injection, Water-cooled Diesel (US Tier-4 Final)
• Horsepower: 24 HP @ 2600 RPM
• Displacement: 71.7 in³ (1175 cc)
• Cylinders: 3
• Fuel Tank: 5.8 gallons (22 L)
• Bore & Stroke: 3.1 in x 3.2 in
• Drive Train:
• Transmission: HST – 2 ranges (Hydrostatic)
• Speeds: Infinite
• Clutch: Dry-Single
• Max Speed: 8.8 mph
• Brakes: Wet Disc
• PTO:
• Type: Independent
• Rear PTO: 540 RPM @ 2550 RPM
• Mid PTO: 2500 RPM @ 2550 RPM
• PTO Power: 16.9 HP (12.26 kW)
• Hydraulics:
• Type: Open Center
• Total Flow: 7.1 GPM (26.9 L/min)
• Main Pump Output: 4.5 GPM
• Steering Pump Output: 2.6 GPM
• 3-Point Hitch: CAT I Narrow with Check Chains
• Lift Capacity @ 24" aft: 1323 lbs (600 kg)
• Electrical:
• Battery: 12 V, 450 CCA
• Alternator: 12 V, 50 A
• Dimensions & Weight:
• Length: 100.5 in (2552 mm)
• Wheelbase: 57.5 in (1460 mm)
• Turning Radius: 7.2 ft (2.1 m)
• Width: 45.8 in (1164 mm)
• Height: 78.2 in (1986 mm)
• Ground Clearance: 9.4 in (240 mm)
• Weight: 1870 lbs (850 kg)
• Tires:
• Ag: Front 6x12 / Rear 9.5x16
• Industrial: Front 20x18-10 / Rear 27x12.5-15
• Turf: Front 20x8-10 / Rear 29x12.5-15
• Loader:
• Model: 25L
• Max Lift Height: 75.3 in
• Lift Capacity: 1323 lbs (600 kg)
• Digging Depth: 4.1 in
