Description :

Specification:

• Engine:
• Type: Four Stroke, Direct Injection, Water-Cooled Diesel
• Engine HP [kW] @ RPM: 48 (35.8) @ 2300
• Displacement (in³): 166.7 (2732)
• Number of Cylinders: 4
• Compression Ratio: 18.7 : 1
• Low Idle RPM: 750 ± 50
• High Idle RPM: 2500 ± 50
• Power Take Off (PTO):
• Type: Live
• Rear PTO RPM: 540 @ 2058
• PTO HP [kW]: 38 (28.3)
• Dash Instruments:
• Tachometer & Hour Meter
• Fuel Gauge
• Temperature Gauge
• Indicators for Warning Messages
• 4WD Drive Lamp
• Safety Equipment:
• Foldable ROPS w/ Retractable Seat Belt
• Safety Start Switches
• Turn Signals/ Hazard Lights
• Mechanical Wet Disc Brakes
• Electric Key Shut Off
• Parking Brake Indicator on Dash
• Water Temperature Gauge
• Horn
• Drive Train:
• Number of Speeds: 8F / 2R
• Clutch: Dual
• Brakes: Fully Enclosed Dry Disc
• Hydraulics:
• Type: Open Center, Full-Live Hydraulic w/ Position & Draft Controls
• 3-Point Hitch: CAT I & II w/ Telescopic Stabilizer
• Lift Capacity lb (kg): 3527 (1599)
• Operator Station:
• Wide Platform Steps
• Color Coded Controls
• Tool Box
• mComfort Seat w/ Adjustable Mechanical Suspension
• Front Axle:
• Power Steering
• Square Tube Design
• Level Gears for Wider Steering
• Electrical:
• Battery: 12 V, 96 Ah
• Alternator: 12 V, 45 A
• Starter Capacity: 12 V, 2.0 kW
• Dimensions:
• Overall Length in (mm): 127 (3225)
• Overall Width in (mm): 82.6 (2098)
• Overall Height in (mm): 93.7 (2379)
• Wheelbase in (mm): 76.7 (1948)
• Turning Radius ft (m): 10.5 (3.2)
• Weight lb (kg): 5192 (2360)
• Wheels & Tires:
• AG [Front/Rear]: 9.5 x 16 / 12.4 x 28
• IND [Front/Rear]: 12.6 x 16.5 / 16.9 x 24
• Capacities:
• Fuel Tank gal. (L): 14.5 (54.8)
• Cooling System gal. (L): 2.2 (8.3)
• Engine Oil gal. (L): 2 (7.5)
• TRANS & DIFF gal. (L): 10.5 (39.7)
