Description:

The 1100 series is the toughest, friendliest, and smartest tractors in the world. We challenge all weekend warriors to test their mettle. Novices will smile at an intuitive and informative cockpit. Phone app lovers will be pumped by its intelligent OJA software.

Specifications:

• Engine:
• Type: Naturally Aspirated, Indirect Injection, Water Cooled Diesel
• Horsepower: 20.1 HP @ 2900 RPM
• Displacement: 67.2 in³ (1102 cc)
• Cylinders: 3
• Fuel Tank: 6.6 gallons (25 L)
• Bore & Stroke: 3 in x 3.2 in
• Drive Train:
• Transmission: HST – 2 range (Hydrostatic)
• Speeds: Infinite
• Max Speed: 7.3 mph
• Brakes: Single pedal
• PTO:
• Type: Independent Wet Clutch
• Rear PTO: 540 RPM @ 2837 RPM
• Mid PTO: 2500 RPM @ 2837 RPM
• PTO Power: 14 HP
• Hydraulics:
• Type: Open center with Position Control
• Total Flow: 7.6 GPM (28.7 L/min)
• Main Pump Output: 7.4 GPM
• Steering Pump Output: 3.8 GPM
• 3-Point Hitch: Category I
• Lift Capacity (24" aft): 771 lbs (350 kg)
• Electrical:
• Battery: 12.6 V, 650 CCA
• Alternator: 12V, 55A
• Dimensions & Weight:
• Length: 100.4 in (2550 mm)
• Wheelbase: 55.1 in (1400 mm)
• Turning Radius: 7.2 ft (2.2 m)
• Width: 46.3 in (1177 mm)
• Height (ROPS): 86.6 in (2200 mm)
• Ground Clearance: 6.7 in (169 mm)
• Weight: 1620 lbs (735 kg)
• Tires:
• Industrial (IND): Front 18×8.5-10 / Rear 26×12-12
• Turf: Front 16×7.5-10 / Rear 24×12-12
• Loader:
• Model: L11
• Max Lift Height: 73.2 in
• Lift Capacity: 794 lbs (360 kg)
• Digging Depth: 3.14 in
